| Specifications
Main Processor: |
Embedded processor |
| Operating System: |
Embedded linux |
SMD Plus:
|
| Performance: |
8 channels |
| AI Search: |
Search by target classification (Human, Vehicle) |
Video and Audio:
|
| Analog Camera Input: |
16 channels, BNC |
| HDCVI Camera: |
1080p@ 25/30 fps, 720p@ 25/30 fps |
| AHD Camera: |
1080p@ 25/30 fps, 720p@ 25/30 fps |
| TVI Camera: |
1080p@ 25/30 fps, 720p@ 25/30 fps |
| CVBS Camera: |
PAL/NTSC |
| IP Camera Input: |
16+2 channels, each channel up to 6MP |
| Audio In/Out: |
1/1, RCA |
| Two-way Talk: |
Reuse audio in/out, RCA |
Recording:
|
| Video Compression: |
AI Coding/H.265+/H.265/H.264+/H.264 |
| Resolution: |
1080N; 720p; 960H; D1; HD1; BCIF; CIF; QCIF |
| Record Rate: |
Main Stream:the 1st channel 1080N/720p (1 fps–25/30 fps), others 1080N/720p (1 fps–15 fps); 960H/D1/HD1/BCIF/CIF/QCIF (1 fps–25/30 fps)
Substream:
CIF/QCIF (1 fps–7 fps) |
| Video Bit Rate: |
32 kbps–4096 kbps per channel |
| Record Mode: |
Manual; Schedule (General, Continuous); MD (Video detection: Motion Detection, Video Loss, Tampering); Alarm; Stop |
| Record Interval: |
1 min–60 min (default: 60 min), Pre-record: 1 sec–30 sec, Post-record: 10 sec–300 sec |
| Audio Compression: |
G.711A; G.711U; PCM |
| Audio Sample Rate: |
8 kHz, 16 bit per channel |
| Audio Bit Rate: |
64 kbps per channel |
Display:
|
| Interface: |
1 HDMI; 1 VGA |
| Resolution: |
1920 × 1080, 1280 × 1024, 1280 × 720 |
| Multi-screen Display: |
When IP extension mode not enabled: 1/4/8/9/16When IP extension mode enabled: 1/4/8/9/16 |
| OSD: |
Camera title; Time; Video loss; Camera lock; Motion detection; Recording |
Network:
|
| Interface: |
1 RJ-45 Port (100 MB) |
| Network Function: |
HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; P2P; IP Search (Supports Dahua IP camera, DVR, NVS, etc.) |
| Max. User Access: |
128 users |
| Smart Phone: |
iPhone; iPad; Android |
| Interoperability: |
ONVIF 16.12, CGI Conformant |
Video Detection and Alarm:
|
| Trigger Events: |
Recording; PTZ; Tour; Video Push; Email; FTP; Snapshot; Buzzer and Screen Tips |
| Video Detection: |
Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis |
| Alarm input: |
N/A |
| Relay Output: |
N/A |
Playback and Backup:
|
| Playback: |
1/4/9/16 |
| Search Mode: |
Time/Date, Alarm, MD and Exact Search (accurate to second) |
| Playback Function: |
Play; Pause; Stop; Rewind; Fast play; Slow Play; Next File; Previous File; Next Camera; Previous Camera; Full Screen; Repeat; Shuffle; Backup Selection; Digital Zoom |
| Backup Mode: |
USB Device/Network |
Storage:
|
| Internal HDD: |
1 SATA port, up to 6 TB capacity |
| eSATA: |
N/A |
Auxiliary Interface:
|
| USB: |
2 USB ports (USB 2.0) |
| RS232: |
N/A |
| RS485: |
N/A |
Electrical:
|
| Power Supply: |
DC 12V/2A |
| Power Consumption(Without HDD): |
< 10W |
Construction:
|
| Dimensions: |
Compact 1U, 260.0 mm × 231.4 mm × 47.6 mm(10.24” × 9.11” × 1.87”) |
| Net Weight(without HDD): |
0.89 kg (1.96 lb) |
| Gross Weight: |
1.42 kg (3.13 lb) |
| Installation: |
Desktop installation |
Environmental:
|
| Operating Conditions: |
-10°C to +45°C (+14°F to +113°F), 10%–90% (RH) |
| Storage Conditions: |
-20°C to +70°C (-4°F to +158°F), 0%–90% (RH) |
Third-party Support:
|
| Third-party Support: |
Dahua, Arecont Vision, AXIS; Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
Certifications:
|
| Certifications: |
FCC: Part 15 Subpart B |
| CE: CE-LVD: EN 60950-1/IEC 60950-1CE-EMC: EN 61000-3-2; EN 61000-3-3; EN 55032; EN 50130; EN 55024 |
| UL: UL 60950-1 |
